Knox G4 Pro 40.5k/60kpV 40.5KW On-Grid Solar Inverter With 60000W PV

The Xerox G4 Pro 40.5K/60kpV is a high-efficiency, three-phase solar inverter designed for commercial use. It delivers 40,500 W of AC power and supports up to 60,000 Wp of PV array input (150% oversizing) . With a wide MPP voltage range (180V1000V) and 4 independent MPPT inputs , it ensures maximum energy harvest even under partial shading thanks to ShadeSol technology . The unit features IP66 protection , making it suitable for both indoor and outdoor installations, and includes smart monitoring via the Ai Solar App . It offers advanced safety features and active cooling for reliable long-term performance.Download DataSheet ModelG4 Pro 40.5K/60kpVInstallation MethodQuick and easy-to-install with standard toolsSetup & MonitoringSmart setup, commissioning and monitoring via Ai Solar AppDesignCompact wall mountStandardsIEC62109-1, IEC62109-2, IEC62727, IEC62683, IEC62116PV Array Oversizing (STC)Up to 150% (60,000 Wp)Protection RatingIP66 (suitable for indoor and outdoor use)MPP Voltage Range180 V 1000 VShadeSol TechnologyYes (improves generation under non-ideal conditions)Max Altitude3000 mRated Active Power40,500 WRated Apparent Power40,500 VAAC Nominal Voltage230 V / 400 VAC Voltage Range160 V 300 VAC Grid Frequency50 HzAC Grid Frequency Range45 Hz 55 HzRated Output Current63.8 AInput Voltage at MPP Range180 V 1000 VMinimum Input Voltage160 VInitial Feed-in Voltage200 VNo. of Independent MPPT Inputs4Strings per MPPT InputA:2; B:2; C:1; D:1Max Efficiency98.70%European Efficiency98.30�justable Power Factor Range0.8 Leading to 0.8 LaggingHarmonic Distortion (THD)Ground Fault MonitoringYesDC SwitchYesGrid MonitoringYesDC Reverse Polarity ProtectionYesAC Short Circuit ProtectionYesResidual Current Monitoring UnitAll-pole-sensitiveAnti-Islanding ProtectionYesSurge ProtectionYesProtection Class (IEC 62109-1)AC: III; DC: IIOvervoltage CategoryIIDimensions (W x H x D)574 mm x 513.5 mm x 234.5 mmWeight29.5 kgOperating Temperature RangeNot specifiedSelf-consumption (at night)TopologyNon-isolatedCooling ConceptActive coolingClimatic Category (IEC 60721-3-4)4K4H (non-condensing)Mounting TypeWall-mount bracketDC ConnectionPlug-in connectorAC ConnectionPlug-in connectorLED IndicatorsStatus / Fault / CommunicationCommunication InterfaceRS485 / Wi-Fi / LAN / 4G
