Raspberry Pi 500 Desktop Kit | SC2093 | US Layout Raspberry Pi 500 is a premium computer built into a high-quality mechanical keyboard, redefining the compact PC experience for power users and enthusiasts. The Raspberry Pi 500 is a powerful computer built into a premium mechanical keyboard, pairing a quad-core 64-bit ARM processor with 16GB of memory and a fast 256GB SSD. It delivers smooth performance, dual 4K output, and the satisfying feel of Gateron KS-33 Blue switches with RGB lighting. For those times when the keys feel a little too clicky, Key Dampeners can provide a simple way to soften keystrokes and cut down noise without losing the mechanical feel. Tools are included for opening the case to replace the SSD and for swapping out the default keycaps. Make sure to check the comprehensive instructions. Key features 2.4GHz quad-core, 64-bit Arm Cortex-A76 CPU, with 512KBL2 caches and a 2MB shared L3 cache VideoCore VII GPU 16GB LPDDR4X-4267 SDRAM 2.4 GHz and 5.0 GHz 802.11ac Wi-Fi Bluetooth 5.0 / Bluetooth Low Energy (BLE) 256GB SSD pre-loaded with Raspberry Pi OS Micro SD card slot, with support for high-speed SDR104mode and the command queuing extension 2 × USB 3.0 ports, supporting simultaneous 5Gbps operation 1 × USB 2.0 port Gigabit Ethernet Dual micro-HDMI ports 78-, 79- or 83-key (depending on regional variant)mechanical keyboard 40-pin GPIO header Kensington lock 5V/5A DC power – via separate USB-C power supply Power button on the keyboard Specifications Processor: 2.4GHz quad-core 64-bit Arm Cortex-A76 CPU, with cryptography extensions, 512KB per-core L2 caches and a 2MB shared L3 cache Memory: 16GB LPDDR4X-4267 SDRAM Connectivity: Dual-band (2.4GHz and 5.0GHz) IEEE 802.11b/g/n/ac Wi-Fi® Bluetooth 5.0, BLE Gigabit Ethernet 2 × USB 3.0 ports and 1 × USB 2.0 port 2 × micro HDMI ports GPIO Horizontal 40-pin GPIO header Display outputSupports up to dual 4Kp60 Multimedia H.265 (4Kp60 decode), OpenGL ES 3.0 graphics Storage 256GB Raspberry Pi SSD pre-installed with Raspberry Pi OS Support for M.2 NVMe SSDs up to 2280 (22mm × 80mm) form factor microSD card slot for operating system and data storage Keyboard 84-, 85- or 88-key mechanical keyboard (depending on regional variant), Gateron KS-33 Blue low-profile switches Power 5V DC via USB connector Operating temperature 0°C to 50°C Dimensions 312mm × 123.06mm × 35.76mm Kit includes Raspberry Pi 500 (US Keyboard layout) Raspberry Pi Power Supply Mouse Official Raspberry Pi Beginner’s Guide (English) 1 × micro HDMI to HDMI-A cable, 1m Resources Raspberry Pi 500 product brief SSD replacement instructions
